Part #9 – Housing

 MATERIAL:  316 Stainless Steel FINISH:  Passivation INDUSTRY:  Aerospace DESCRIPTION:  Machined complete from 316 stainless steel bar.  Multiple features positioned in relation to each other to extremely tight tolerances. TOLERANCE:  +/-.0002 bore diameter.  Multiple diameters to +/-.001.  Position of holes/features to datums within .001. ANNUAL USAGE:  100-200

19
Oct

Part #8 – Cover

 MATERIAL:  Cold Rolled Steel FINISH:  Paint INDUSTRY:  Aerospace DESCRIPTION:  Covers cut, welded and machined to customer spec.  Primed and painted to finish specifications. TOLERANCES:  +/-.005 ANNUAL USAGE:  <10

29
Aug

Part #7 – Tooling Assembly

 MATERIAL:  Cold Rolled Steel FINISH:  Case Hardened/Black Oxide INDUSTRY:  Automotive DESCRIPTION:  Assembly for automotive tooling.  Parts machined complete and one component geared by outside vendor.  Finished and assembled for customer in-house. TOLERANCES:  +/-.001 on multiple dimensions for fit and function. ANNUAL USAGE:  100-200

6
Jun

Part #6 – Motor Housing

 MATERIAL: 6061 Aluminum FINISH:  Clear Anodize and Clear Chemical Film INDUSTRY:  Aerospace DESCRIPTION:  Motor housing for aerospace/military industry.  Machine finish and metal finish all critical to finished product. TOLERANCE:  +/-.0002 on bore diameter.  Multiple position tolerances .001 to multiple datums. ANNUAL USAGE: <100

18
May

Part #5 – Wafer Mount

MATERIAL:  7075 Aluminum FINSH:  Hardcoat Anodize Black INDUSTRY:  Semiconductor/Capital Equipment DESCRIPTION:  Machined completed from aluminum plate.  Finish, flatness, and parallelism critical. TOLERANCES:  +/-.0005 on multiple holes.  .002 flat from bottom pads to top surface. ANNUAL USAGE:  <50

15
Apr

Part #4 – Fusion Tool Assembly

MATERIAL: 6061 Aluminum/303 SSt/Class L Shafting/Misc Hardware FINISH: Clear Anodize INDUSTRY: Industrial Equipment DESCRIPTION: Machined to specifications and assembled with precision ground shafting aligned with honed oilite bushings and assembled with designated hardware. Cleaned, assembled, and packaged for customer to ship directly to end user. TOLERANCE:  +/-.005 on most features.  Multiple +/-.001 tolerances for ease of assembly and …

3
Apr

Part #3 – Hand Scanner Base

MATERIAL: 6061 Aluminum FINISH: Clear Anodize INDUSTRY: Biometics DESCRIPTION: Platform for biometric palm reader.  Machined complete from 6061 aluminum block and bead blasted prior to clean anodize.  Multiple contoured features for aesthetics. TOLERANCE:  +/-.005 on most features. ANNUAL USAGE: 100-200

24
Apr

Part #2 – Spindle

MATERIAL: 440c Stainless Steel FINISH: Electroless Nickel Plate INDUSTRY: Capital Equipment/Semiconductor DESCRIPTION:  Hardened to 45-48 Rc.  Electroless nickel plate finish. TOLERANCE:  +/-.0002 on shaft.  Multiple +/-.001 features. ANNUAL USAGE: 10-20

27
Jul

Part #1 – Scanner Housing

MATERIAL: 6061 Aluminum FINISH: Black Hardcoat Anodize INDUSTRY: Biometrics DESCRIPTION: Milled from solid aluminum block. Machining on all six sides with complex geometry and fixtures designed to machine economically. TOLERANCE:  +/-.005 ANNUAL USAGE: 50-100
